Description
Improves Picture and Sound Quality
The PM8-AV’s Power Cleaning and Filtration eliminate common symptoms of contaminated power (including loss of detail, pops, hisses, hums and
visual artifacts) and allows your A/V equipment to perform up to its full capability.
Surge Protection
Exclusive Protect or Disconnect™ circuitry. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to
connected equipment.
Safety
Engineered and built to meet the latest UL Safety requirements (UL 1449 3rd Edition)
Features
Cable/Sat Protection
Protects equipment from electrical surges that travel over cable, satellite, and antenna lines.
Telephone Line Protection
Protects equipment from electrical surges that travel over telephone lines.
8 Outlets
Eight (8) filtered and surge protected outlets.
Surge Protection
Exclusive Protect or Disconnect™ circuitry. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to
connected equipment.
Hi Def Ready
Hi-Def Designed to work with your High Definition system.
Specifications
Voltage Protection Rating (UL 1449 3rd Edition, 3,000A): 500V
Thermal Fusing: Yes
Single Pulse Energy Dissipation: 1125 Joules
Response Time:
< 1 ns
Peak Impulse Current: 52,000 Amps
Telco Protection
Wires Protected: 1 Line (3, 4)
Suppression Modes: Metallic & Longitudinal
Fuseless / Auto-reseting: Yes
Connectors:
RJ-11
Clamping Level: 260V
Capacitance: 30pf (approx.)
Universal Coaxial Protection
Shielded: Yes
Insertion Loss:
< 0.5 dB
Frequency Range: OMHz – 2.2 GHz
Connections: Female “F”, Gold Plated
Clamping Level: 75V
Bidirectional: Yes
Warranty
$100,000 LIFETIME LIMITED CONNECTED EQUIPMENT PROTECTION POLICY
LIFETIME LIMITED PRODUCT WARRANTY
Panamax warrants to the purchaser of any standard Panamax surge protector that the surge protector shall be free of defects in design, material,
or workmanship, and Panamax will repair or replace any defective unit.
WARRANTY LIMITATION FOR INTERNET PURCHASERS:
Panamax products purchased through the Internet do not carry a valid Connected Equipment Protection Policy unless purchased from an Authorized
Panamax Internet Dealer! Authorized Panamax Internet Dealers have sufficient expertise to insure warranty compliant installations.
